4. Commissioning
4−9
Festo P.BE−CPV−EN en 0503g
4.2.2 Checking the valve−cylinder combination
Carrying out the test Proceed as follows:
1. Switch on the compressed air supply.
2. Check the functioning and operation of each indi vidual
valve−cylinder combination by actuati ng the manual ove rri de
as shown in the following diagrams.
Please note
Incorrect actuation of the non−locking manual override can
lead to malfunctioning or damage to the manual override.
· Use a blunt pencil for actuating the non−locking manual
override.
· Actuate the manual override only with max. 30 N.
3. In the case of the CPV valve terminal with pneumatic
multipin: After testing the valves, make sure that all
manual override actuations are in their basic positions.
4. Switch off the compressed air supply after checking the
valves.
