2. Fitting
2−18
Festo P.BE−CPV−EN en 0503g
2.2.1 Fitting the pneumatic multipin
Make sure that the fastening surface can support the pneu
matic multipin and the CPV valve terminal. Make sure that
there is sufficient space for connecting the supply cables and
tubing, and that extra space is available for fitting CPV valve
terminals with large surface−mounted silencers.
Fitting the pneumatic multipin (connection side)
Proceed as follows in order to fit the pneumatic multipin with
the connection side onto a mounting surface:
· Cut out an opening in the fastening surface (dimensions
see table 2/11 or table 2/12).
· Drill four mounting holes in the fastening surface (diam
eter see table). Position of and distance between these
holes (see table 2/11 or table 2/12).
· Screw the pneumatic multipin to the fastening surface
with four screws of sufficient length (see table).
Pneumatic multipin
(without step)
Pneumatic multipin
(with step)
CPV10/14 CPV18 CPV10/14/18
4.5 mm 5.5 mm 6.5 mm
M4 M5 M6
Tab.2/10: Diameter of the fastening holes and screw size
