Festo CPV10 - Hat Rail Adapter, Tightening Torques; Hat Rails

2. Fitting
2−10
Festo P.BE−CPV−EN en 0503g
Proceed as follows:
· Make sure that the fastening surface can support the
weight of the CPV valve terminal.
· Fit the following hat rail:
Hat rail for CPV10/14
valve terminal
Hat rail for CPV18
valve terminal
Support rail DIN 50022 − 35x7.5;
width 35 mm, height 7.5 mm)
Support rail DIN 50022 − 35x15
(width 35 mm, height 15 mm)
Tab.2/6: Hat rails
· Make sure that there is sufficient space for connecting the
supply cables and tubing, and that extra space is avail
able for fitting CPV valve terminals with large surface−
mounted silencers.
· Fasten the hat rail to the fastening surface approximately
every 100 mm.
· Fasten the two brackets to the end plates with the screws
supplied as shown in the diagram below. With CPV10/14
valve terminals, make sure that the fastening bolts of the
brackets grip into the recess in the CPV valve terminal.
CPV valve
terminal
Self−threading
screw
Tightening torque
CPV10/14 M4x10 1.5 Nm
CPV18 M5x10 4 Nm
Tab.2/7: Hat rail adapter, tightening torques
