2. Installation
2−6
Festo P.BE−CPX−CEC−EN en 1004a
2.3 Connection and display elements
2
3
4
6
7
5
1
1
Status LEDs
2 RUN/STOP rotary switch
3 Ethernet interface
(10/100BaseT, RJ45)
4 CPX−CEC−C1/−M1:
CANopen interface
(plug, 9−pin, Sub−D )
CPX−CEC:
RS232 interface
(socket, 9−pin, Sub−D)
5 DIL switch 1
6 DIL switch 2
7 Connection for a handheld of type
CPX−MMI
Fig.2/2: Connection and display elements (here for CPX−CEC−C1/−M1 as an example)
