Festo CPX-CEC - Diagnosis via controller LEDs

4. Diagnosis
4−5
Festo P.BE−CPX−CEC−EN en 1004a
4.2 Diagnosis via controller LEDs
The controller LEDs have the following meaning:
RUN  PLC status: star ted
LED (green) Sequence Status Error number Error handling
LED lights up
ON
OFF
PLC program started
(RUN/STOP switch is in
position "1 ... F")
 
LED is off
ON
OFF
PLC program stopped
(RUN/STOP switch is in
position "0")
 · Set RUN/STOP
switch to position
"1 ... F"
Tab.4/2: Displays of RUN LED
STOP  PLC status stopped
LED (yellow) Sequence Status Error number Error handling
LED lights up
ON
OFF
PLC program stopped
(RUN/STOP switch is in
position "0")
 
LED is off
ON
OFF
PLC program started
(RUN/STOP switch is in
position "1 ... F")
 · Set RUN/STOP
switch to position
"0"
Tab.4/3: Displays of STOP LED
