Festo CPX-CEC - Parameterisation Via the Handheld Type CPX−MMI

3. Commissioning
3−13
Festo P.BE−CPX−CEC−E N en 1004a
3.5.2 Parameterisation via the handheld type CPX−MMI
The parameters of the CPX terminal can be read and modified
via a connected handheld.
Transfer of the parameterisation to the CPX modules
Note
· Parameterisations via the handheld are saved only
locally in the CPX terminal and are lost with Power
OFF/ON.
· The connection with the CPX−MMI is interrupted during a
program download if parameters have been changed via
the CoDeSys provided by Festo software.
· Parameters changed by the CPX−MMI and Festo_CPX.lib
are only then overwritten during the project download if
parameter changes have also been made in the CoDeSys
project.
Further information on parameterisation via CPX−MMI can be
found in the manual P.B E−CPX−MMI−1−...
