2.4.2 DIL switches
The DIL switches must be accessible in order to make
settings:
· Remove, if applicable, the cover or an IP65/IP67 plug
from the Sub−D interface.
DIL switch 1
DIL switch 1 is reserved. Leave the two switch elements of
DIL switch 1 at OFF.
CPX−CEC/CPX−CEC−...
DIL switch 1
Reserved DIL 1.1: OFF
DIL 1.2: OFF
Tab.2/2: Setting the DIL switch 1
