2.9 Complying with protection class IP65/IP67
In order to comply with protection class IP 65/IP67, seal un
used sockets and the switch with the appropriate covers.
Connection/
switch
Connection
IP65/IP67
Cover
1)
IP65/IP67
Ethernet, RJ45 Plug
type FBS−RJ45−8−GS
Cover
2)
type AK−RJ45
Sub−D (CANopen/
RS232) and
DIL switch
Plug type FBS−
SU B−9−BU−
2X5POL−B
Transparent cover
2)
type AK−SUB−9/15−B
Service interface,
M12
Connecting cable and
plug of the CPX−MMI
Protective cap
2)
type ISK−M12
Rotary switch  Cover
2)
type AK−RJ45
1)
If connection is not used
2)
Included in scope of delivery
Tab.2/8: Connections and covers for protection class
IP65/IP67
