A. Technical appendix
A−4
Festo P.BE−CPX−CEC−E N en 1004a
CPX−CEC/CPX−CEC−...
LED display (product−specific) RUN: PLC status: star ted
STOP: PLC status: stopped
ERR: PLC run−time error
PS: Electronic supply,
sensor supply
PL: Load supply
SF: System fault
M: Modify/forcing active
Fieldbus interface (CPX−CEC−C1/−M1)
 Type
 Connection technology
 CPX−CEC−C1 transmission rate
 CPX−CEC−M1 transmission rate
 Electrical isolation
CAN bus
Plug, Sub−D, 9−pin
125; 250; 500; 800; 1,000 kbps
(adjust. via software)
125; 250; 500; 1,000 kbps
(adjust. via software)
Yes
Data interface (CPX−CEC)
 Type
 Connection technology
 Transmission speed
 Electrical isolation
RS232 interface
Socket, Sub−D, 9−pin
9.6 ... 230.4kbps
Yes
Ethernet
 Number
 Connector plug
 Transmission speed
 Supported protocols
1
RJ45, socket, 8−pin
10/100mbps
TCP/I P, EasyIP, Modbus TCP
Protection class
only in conjunction with plugs and covers in
protection class IP65/IP67
IP65/IP67
Nominal operating voltage 24V DC
Load voltage
 without pneumatics
 with pneumatics type Midi/Maxi
 with pneumatics type CPA
 with pneumatics type MPA
18 ... 30V DC
21.6 ... 26.4V DC
20.4 ... 26.4V DC
18 ... 30V DC
Intrinsic current consumption
at rated voltage Typically 85 mA
