3.4.3.1 System parameters
System parameters describe the peripherals attached to a valve, using attributes such as tube length,
cylinder type and mounting position. The system parameters of a parameter set apply jointly to all
Motion Apps running on a valve, but the parameters are not used by all Motion apps.
The parameters required to run a Motion App must be transferred before starting the Motion App.
Overview of system parameters
ID System parameters
12 Tube length at (2)
13 Tube length at (4)
14 Tubing internal diameter at (2)
15 Tubing internal diameter at (4)
20 Drive type
21 Drive stroke
40 Volume at (2)
41 Volume at (4)
42 Operating medium
60 Mounting position of drive
61 Axis zero point offset
70 Sensor input for end position detection, retracted
71 Sensor input for end position detection, advanced
75 Sensor input for partial stroke measurement, retracted
76 Sensor input for partial stroke measurement, advanced
80 Sensor input for full stroke measurement
81 Sensor input for flow measurement at (2)
82 Sensor input for flow measurement at (4)
Tab. 12: Overview of system parameters
Tube length at (2)
ID Value range Value digit Digit range
12 0 … 20000 mm 1 mm 0 … 20000 × 1 mm
Tab. 13: Tube length at (2)
