ID Parameter Value range Value digit Digit range
1 Detection range (max-
imum value)
1)
1 … 3000 l/min 1 l/min 1 … 3000 × 1 l/min
2 Lower limit of the
measured values to be
assumed as reliable
2)
0.1 … 10% 0.1% 1 … 100 × 0.1%
Interpretation of the measured signal: 4 mA Z 0 l/min
20 mA Z maximum value sensing range
1) Maximum value of the interpreted flow rate with reference to the operating medium to be used at 0 °C. With a different sensor
reference standard, the maximum flow rate value specified in its datasheet must be converted accordingly.
2) relative to the maximum value of the sensing range
Tab. 36: Parameters for describing user-defined flow sensors
The specified maximum value of the interpreted flow rate refers to the operating medium used at 0
°C. With a different sensor reference standard, the maximum flow rate value specified in its datasheet
must be converted accordingly.
The parameters for the description of user-defined flow sensors are not included in the parameter sets
because they are independent of the valves.
3.4.3.7
Parameters for the description of user-defined drives
The storage of user-defined drives is optional. As a rule, drives from the list of supported drives can be
used. No further description of them is required by the user.
è
6.2 List of supported drives
Up to eight user-defined drives can be stored on the device for support of special applications with
drive combinations or drives that are not listed in the list of supported drives. They can then be
selected for use on a valve using the "Drive type" system parameter.
The physical properties of a user-defined drive are defined using the following parameters. The
parameters for description of user-defined drives are read and written via channel 17 (user-defined
peripherals) of the transfer mode and can be performed via the process data of any valve
è
4.4 Set
parameters for the description of user-defined drives. A drive defined in this way is available for all
valves of the Motion Terminal.
Not all physical properties of a drive are known. Notes on which parameters for the description of a
user-defined drive are particularly relevant for operation with a specific Motion App and specifications
for any approximate specifications are included in the list of supported drives
è
6.2 List of supported
drives.
ID Parameter Value range Value digit Digit range
1 Design 1 = single-acting piston rod cylinder
2 = double-acting piston rod cylinder
3 = rodless cylinder (linear drive)
