Festo VTEM - Page 56

56
Festo — VTEM — 2021-05f
Function
Booster strokes (degree of opening)
Channel 25, addressed target 13
Index Meaning Value digit
Valve Working air port Booster
161 7 2 Pressurisation 0.01%
162 Exhaust 0.01%
163 4 Pressurisation 0.01%
164 Exhaust 0.01%
Tab. 68: Booster strokes
Flow rates at valve (volumetric flow rate)
1)
Channel 25, addressed target 14
Index Meaning Value digit
Valve Working air port
22 0 2 0.1 rpm
24 4 0.1 rpm
26 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
42 1 2 0.1 rpm
44 4 0.1 rpm
46 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
62 2 2 0.1 rpm
64 4 0.1 rpm
66 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
82 3 2 0.1 rpm
84 4 0.1 rpm
86 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
102 4 2 0.1 rpm
104 4 0.1 rpm
106 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
