Function
57
Flow rates at valve (volumetric flow rate)
1)
Channel 25, addressed target 14
Index Meaning Value digit
Valve Working air port
122 5 2 0.1 rpm
124 4 0.1 rpm
126 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
142 6 2 0.1 rpm
144 4 0.1 rpm
146 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
162 7 2 0.1 rpm
164 4 0.1 rpm
166 2 (Low Byte, signed) 10 rpm
4 (High Byte, signed) 10 rpm
1) Volumetric flow rate assuming a density of air in standard conditions in accordance with ISO 8778/DIN 1945-1 (density 1.1850 kg/m³
of dry air at 20 °C) as a function of the current valve strokes and pressures at (1), (2) or (4) and (3). The pressure signals are used
unfiltered, so the return values will vary under the same conditions according to the noise of the pressure sensors.
Tab. 69: Flow rates at the valve
