Function
Proximity signals
Channel 25, addressed target 21
Index Meaning Value digit
193 Raw value from proximity switch at input module 1, port 6 1
194 Interpreted value from proximity switch at input module 1, port 6 1
195 Raw value from proximity switch at input module 1, port 7 1
196 Interpreted value from proximity switch at input module 1, port 7 1
201 Raw value from proximity switch at input module 2, port 0 1
202 Interpreted value from proximity switch at input module 2, port 0 1
203 Raw value from proximity switch at input module 2, port 1 1
204 Interpreted value from proximity switch at input module 2, port 1 1
205 Raw value from proximity switch at input module 2, port 2 1
206 Interpreted value from proximity switch at input module 2, port 2 1
207 Raw value from proximity switch at input module 2, port 3 1
208 Interpreted value from proximity switch at input module 2, port 3 1
209 Raw value from proximity switch at input module 2, port 4 1
210 Interpreted value from proximity switch at input module 2, port 4 1
211 Raw value from proximity switch at input module 2, port 5 1
212 Interpreted value from proximity switch at input module 2, port 5 1
213 Raw value from proximity switch at input module 2, port 6 1
214 Interpreted value from proximity switch at input module 2, port 6 1
215 Raw value from proximity switch at input module 2, port 7 1
216 Interpreted value from proximity switch at input module 2, port 7 1
Tab. 70: Proximity signals
Positions
Channel 25, addressed target 22
Index Meaning Value digit
181 Raw value from position sensor at input module 1, port 0 0.001 mA
182 Interpreted value from position sensor at input module 1, port 0 0.1 mm
183 Raw value from position sensor at input module 1, port 1 0.001 mA
184 Interpreted value from position sensor at input module 1, port 0 0.1 mm
185 Raw value from position sensor at input module 1, port 2 0.001 mA
186 Interpreted value from position sensor at input module 1, port 2 0.1 mm
187 Raw value from position sensor at input module 1, port 3 0.001 mA
