Function
59
Positions
Channel 25, addressed target 22
Index Meaning Value digit
188 Interpreted value from position sensor at input module 1, port 3 0.1 mm
189 Raw value from position sensor at input module 1, port 4 0.001 mA
190 Interpreted value from position sensor at input module 1, port 4 0.1 mm
191 Raw value from position sensor at input module 1, port 5 0.001 mA
192 Interpreted value from position sensor at input module 1, port 5 0.1 mm
193 Raw value from position sensor at input module 1, port 6 0.001 mA
194 Interpreted value from position sensor at input module 1, port 6 0.1 mm
195 Raw value from position sensor at input module 1, port 7 0.001 mA
196 Interpreted value from position sensor at input module 1, port 7 0.1 mm
201 Raw value from position sensor at input module 2, port 0 0.001 mA
202 Interpreted value from position sensor at input module 2, port 0 0.1 mm
203 Raw value from position sensor at input module 2, port 1 0.001 mA
204 Interpreted value from position sensor at input module 2, port 1 0.1 mm
205 Raw value from position sensor at input module 2, port 2 0.001 mA
206 Interpreted value from position sensor at input module 2, port 2 0.1 mm
207 Raw value from position sensor at input module 2, port 3 0.001 mA
208 Interpreted value from position sensor at input module 2, port 3 0.1 mm
209 Raw value from position sensor at input module 2, port 4 0.001 mA
210 Interpreted value from position sensor at input module 2, port 4 0.1 mm
211 Raw value from position sensor at input module 2, port 5 0.001 mA
212 Interpreted value from position sensor at input module 2, port 5 0.1 mm
213 Raw value from position sensor at input module 2, port 6 0.001 mA
214 Interpreted value from position sensor at input module 2, port 6 0.1 mm
215 Raw value from position sensor at input module 2, port 7 0.001 mA
216 Interpreted value from position sensor at input module 2, port 7 0.1 mm
Tab. 71: Positions
Flow rates at the external sensor
Channel 25, addressed target 23
Index Meaning Value digit
181 Raw value from flow sensor at input module 1, port 0 0.001 mA
182 Interpreted value from flow sensor at input module 1, port 0 0.1 rpm
