Function
Flow rates at the external sensor
Channel 25, addressed target 23
Index Meaning Value digit
183 Raw value from flow sensor at input module 1, port 1 0.001 mA
184 Interpreted value from flow sensor at input module 1, port 1 0.1 rpm
185 Raw value from flow sensor at input module 1, port 2 0.001 mA
186 Interpreted value from flow sensor at input module 1, port 2 0.1 rpm
187 Raw value from flow sensor at input module 1, port 3 0.001 mA
188 Interpreted value from flow sensor at input module 1, port 3 0.1 rpm
189 Raw value from flow sensor at input module 1, port 4 0.001 mA
190 Interpreted value from flow sensor at input module 1, port 4 0.1 rpm
191 Raw value from flow sensor at input module 1, port 5 0.001 mA
192 Interpreted value from flow sensor at input module 1, port 5 0.1 rpm
193 Raw value from flow sensor at input module 1, port 6 0.001 mA
194 Interpreted value from flow sensor at input module 1, port 6 0.1 rpm
195 Raw value from flow sensor at input module 1, port 7 0.001 mA
196 Interpreted value from flow sensor at input module 1, port 7 0.1 rpm
201 Raw value from flow sensor at input module 2, port 0 0.001 mA
202 Interpreted value from flow sensor at input module 2, port 0 0.1 rpm
203 Raw value from flow sensor at input module 2, port 1 0.001 mA
204 Interpreted value from flow sensor at input module 2, port 1 0.1 rpm
205 Raw value from flow sensor at input module 2, port 2 0.001 mA
206 Interpreted value from flow sensor at input module 2, port 2 0.1 rpm
207 Raw value from flow sensor at input module 2, port 3 0.001 mA
208 Interpreted value from flow sensor at input module 2, port 3 0.1 rpm
209 Raw value from flow sensor at input module 2, port 4 0.001 mA
210 Interpreted value from flow sensor at input module 2, port 4 0.1 rpm
211 Raw value from flow sensor at input module 2, port 5 0.001 mA
212 Interpreted value from flow sensor at input module 2, port 5 0.1 rpm
213 Raw value from flow sensor at input module 2, port 6 0.001 mA
214 Interpreted value from flow sensor at input module 2, port 6 0.1 rpm
215 Raw value from flow sensor at input module 2, port 7 0.001 mA
216 Interpreted value from position sensor at input module 2, port 7 0.1 rpm
Tab. 72: Flow rates at the external sensor
