Please note
 With the VTSA valve terminal the maximum number of
solenoid coils which can be actuated is limited to
32addresses.
You can configure the valve terminal with maximum
32 single−coil valves on 16 manifold blocks of type
VABV−S4−...−2T1.
You can configure the valve terminal with maximum
16 single−coil valves on 8
manifold blocks of type
VABV−S4−...−2T2.
A.2 Festo accessories
Accessories Type designation
General information
 Blanking plug Gx" / x"NPT
 Blanking plug G¼" / ¼"NPT
 Blanking plug G½" / ½"NPT
 Manual override cap (manual override cannot be operated)
 Manual override cap (manual override can only be operated in
non−locking mode)
 Identification plate for manifold block
 Identification plate for the valve
 Addittional bracket for wall fitting
B−x / B−x−NPT
B−¼ / B−¼−NPT
B−½ / B−½−NPT
VAMC−S6−CS
VAMC−S6−CH
ASCF−M−S6
ASCF−T−S6
VAME−S6−1−W
VTSA valve terminal with MP connection
 Ready−to−use multipin cable with socket:
for terminals with 8 valve solenoid coils
for terminals with 22 valve solenoid coils
for terminals with 23 valve solenoid coils
for terminals with 32 valve solenoid coils
 Hat rail mounting kit (also for valve terminal with terminal strip)
NEBV−S1W37−...−LE10
NEBV−S1W37−...−LE26
NEBV−S1W37−...−LE27
NEBV−S1W37−...−LE37
CPA10
VTSA valve terminal with CPX terminal
Hat rail mounting kit CPX−CPA−BG−NRH
Tab.A/10: Accessories for the VTSA valve terminal
