2. Fitting
2−5
Festo P.BE−VTSA−44−EN en 0509NH
2.2 Fitting variants
You can fit the VTSA valve terminal in one of two ways:
Mounting method
Description
H−rail mounting The valve terminal is suitable for fitting onto
a hat rail (support rail as per EN60715).
There is a guide groove on the back for
hanging the valve terminal onto the hat rail.
Wall mounting The multipin node or the pneumatic inter
face and the end plates contain holes for
fitting the terminal onto a wall.
With valve terminals with more than 5 mani
fold blocks, additional fastening brackets
may be required on the pneumatic supply
plates (see the following instructions and
specifications on vibration and shock in
appendix A, Tab.A/2).
Tab.2/1: Methods of fitting the VTSA valve terminal
Please note
Fit the VTSA valve terminal so that there is sufficient space
for heat dissipation and ensure that the maximum limits
for temperatures are observed (see Technical specifica
tions").
