3.3.6 Operating the VTSA valve termiinal with reversible pressure
regulators
Please note
Operating the VTSA valve terminal with reversible pressure
regulators (identifier P5−...6 or R5−...−10):
· Reversible pressure regulators must not be used on
reversibly operated valve terminals.
· No 2x3/2−way valves with identifier T32C−A / T32U−A /
T32H−A (non−reversible valves) may be operated with
these pressure regulators.
· The combination of reversible 2x3/2−way valves (ident
ifier T32N−A / T32F−A / T32W−A) with reversible pressure
regulators need not be operated in a separate pressure
zone. With this combination pressure is supplied via
channel 1 and the exhaust is vented via channels 3
and 5.
