2. Fitting
2−13
Festo P.BE−VTSA−44−EN en 0509NH
2.3 Fitting/removing the inscription label holder (optional)
An inscription label holder can be fitted onto each manifold
block to enable the valves or work connections to be distin
guished.
Fittnig Clip the label holders into the recesses in the manifold blocks
(see fig.).
Dismantling Pull the label holders out of the support on the manifold
block.
1 Support for label
holder on the
manifold block
2 Inscription label
holder
1
2
Fig.2/4: Fitting the inscription label holder
