3. Installation
3−28
Festo P.BE−VTSA−44−EN en 0509NH
1
1
Valve terminal with multipin node
cage clamp
Valve terminal with CPX terminal
2
Valve terminal with multipin node Sub−D
1
Valve terminal with multipin node M23
round plug
1
1 Earth connection
2 Internal earth connection in the multipin node cage clamp
Fig.3/7: Earth connections of the VTSA valve terminal
