4.3 Checking the valves and the valve−actuator combination
Please note
Before commissioning the VTSA valve terminal, note the
specifications concerning the medium, see chapter
Installation", section Pilot control of the valve solenoid
coils (pilot air)".
The VTSA valve terminal should be commissioned as follows:
Commissioning variants
Activity
Preliminary test of the
pneumatic tubing
Testing the valve−actuator combina
tion by means of the manual override
Complete commissioning of
the complete system
Installing and connecting the
complete system
Program control via PLC/industrial PC
Tab.4/3: Commissioning variants
How to commission the pneumatic components by means of
the manual override is described below.
Commissioning of the CPX terminal is described in the
appropriate manual for the CPX field bus node.
