Light Bar Format
Li Bar 0 = Light Bar off.
** Li Bar 1 = Check Result Mode (Progress Mode).
Li Bar 2 = Check Result Mode (Single Bar Mode).
Li Bar 3 = Capacity Result Mode (Single Dot Mode).
Li Bar 4 = Check Result Mode (Range Position Mode).
Action on Negative Value
Off = Check Mode Disable when Value is less than zero.
** On = Absolute value, all negative values will be deemed and checked as positive ones.
Off = No data output.
Auto 1 = auto print when weight is stable.
Auto 2 = the highest stable weight value (of a weighing process) will be automatically printed when all loads are removed (and gross weight returns to zero or minus).
Auto 3 = the last stable weight value (of a weighing process) will be automatically printed when all loads are removed (and gross weight returns to zero or minus).
Manual = Manual output to printer or computer.
PC = Continuous output.
CMD = Command / information request mode and APP mode.
Scaner = Serial scanner only.
Notes: -
Refer to operation manual for detailed setup information.
Restart instrument (by power off then power on again) after F16 and/or F17 setting is changed under normal operation status.
Machine ID and Group Number
Id = Machine ID number (0000~9999). Press [CE/x10] to skip or clear machine ID.
Gp = Group number (00~99). Press [CE/x10] to skip or clear machine group.
Manual Customer & Product Code Setting
Customer & Product code by keyboard accept both numeric numbers and alphabets. Maximum length = 18 digits.
Enter code starting from H code, then M code and finally L Code. Press [Print/M+] to confirm and end editing after last digit has been input.
Customer & Product code does not support print format 1 (Lab 1).
If a customer/product code has been entered, this code will be included in print format 2, 3, 4 and 5 (Lab 2 ~ Lab 5) automatically.
When keyboard lock is = ON, only [Zero], [Tare], [Set] & [On/Off] key will be accessible during operation status.
