ATTENTION: always use detergents whose manufacturer's label indicates their suitability for scrubbing machines. Do not use acid
or alkaline products or solvents without this indication.
ATTENTION: the dosing system is suitable for frequent maintenance cleaning. Acid or alkaline maintenance detergent can be used
with pH values between 4 and 10 and that do not contain: oxidising agents, chlorine or bromine, formaldehyde, mineral solvents.
The detergents used must be suitable for use with scrubbing machines. Wash the circuit with water after use if the system is not used
daily. The system can be excluded. In case of sporadic use of detergents with pH between 1-3 or 11-14, use the oor scrubbing machine
in the traditional way by adding the detergent in the clean water tank and excluding the dosing circuit.
ATTENTION: always use low-foam detergent. To avoid the production of foam, put a minimum quantity of antifoam liquid in the recovery
tank before starting to clean. Do not use pure acids.
4. Close the cap (20) correctly to prevent liquid coming out when working.
ASSEMBLING THE BRUSH HEAD BRUSHES (SCRUBBING VERSION)
To t the brush on the brush head body, proceed as follows:
1. Take the machine to the maintenance area.
2. Make sure the machine has been secured (see the section titled “SECURING THE MACHINE”).
CAUTION: these operations must be carried out using protective gloves to avoid any possible contact with the edges or tips of metal
objects.
3. Open the machine's left lateral carter (11) (Fig. 11).
4. Remove the left-hand splashguard (22) and move the xing anchors (23) on the brush head body into the maintenance position (Fig. 18).
5. With the brush head UP, insert the brush in the plate housing underneath the brush head, turning it until the three buttons engage with the
niches on the plate itself.
6. Turn in increments until the button is pushed towards the coupling spring and is locked in place (Fig. 19).
N.B.: the image in Fig. 19 indicates the direction of rotation for coupling the left brush; the right brush must be turned in the opposite
direction.
FITTING THE SIDE BRUSH (SCRUBBING VERSION)
To t the side brush on the brush head body, proceed as follows:
1. Make sure the machine has been secured (see the section titled “SECURING THE MACHINE”).
CAUTION: these operations must be carried out using protective gloves to avoid any possible contact with the edges or tips of metal
objects.
2. With the brush head in the rest position, insert the brush into the plate housing underneath the brush head, and turn it until the two buttons
(24) engage with the niches on the plate itself (Fig. 20).
3. Push the brush until the stopper spring on the brush itself has engaged with the niche present on the gearmotor pin.
FITTING THE BRUSH HEAD BODY SIDE SPLASHGUARDS (WASHING VERSION)
To t the side splash guards on the brush head body, proceed as follows:
1. Take the machine to the maintenance area.
2. Make sure the machine has been secured (see the section titled “SECURING THE MACHINE”).
CAUTION: these operations must be carried out using protective gloves to avoid any possible contact with the edges or tips of metal
objects.
3. Open the machine's left lateral carter (11) (Fig. 11).
4. With the brush head raised from the oor, position the side splash guard carter on the brush head body, insert the pins (24) in the brush
head in the slots (23) in the carter (Fig. 21).
N.B.: before inserting the pins (24) in the slots (23) remember to put the xing anchors (22) in the brush head body in the maintenance
position (Fig. 22).
5. When the side splash guard casing is in position turn the xing anchors (22) to the work position.
6. Close the left side casing (11) and repeat everything for the right side casing.
