Fimap MAGNA - Work Modes Overview (Scrubbing, Drying); Scrubbing Without Drying Operation; Scrubbing With Drying Operation

The machine can be used for the following types of work:
• SCRUBBING WITHOUT DRYING;
• SCRUBBING WITH DRYING;
• DRYING;
As an example, we will look at the SCRUBBING WITH DRYING work type. To begin working in this mode, proceed as follows:
1. Make all the checks listed in “PREPARING TO WORK”.
2. Sit on the driver’s seat.
3. Insert the key (1) into the main switch on the control panel. Bring the main switch to its "I" position by turning the key (1) a quarter turn
clockwise (Fig. 1).
N.B.: as soon as the machine turns on, the control board will perform a diagnostics procedure, during which the red LED indicator (2)
on the control panel (Fig. 2) will remain on.
N.B.: if the control board's diagnostics procedure returns a positive outcome, the red LED indicator (2) on the control panel (Fig. 2)
will turn o󰀨, and an acoustic signal will sound indicating that the work operations may be initiated.
4. Lower the brush head body by turning the brush head control lever (3) on the rear part of the steering column (Fig. 3).
5. Lower the squeegee body by turning the squeegee control lever (4) on the rear part of the steering column (Fig. 4).
6. Check to make sure that the detergent solution tap is completely open. If this is not the case, adjust the lever (5) on the left-hand side of the
steering column (Fig. 5).
7. Press the drive pedal (6) (Fig. 6) to begin moving the machine.
N.B.: once the drive pedal is pressed, the brush head body and the squeegee body will begin to descend into their working positions.
N.B.: once the brush head body and the squeegee body have reached their working positions, the relative motors will enter into function,
and the solenoid valve will dispense the detergent solution.
N.B.: during the rst few metres, check that the detergent solution coming out is suitable for the task in hand. If it isn't, adjust it after
reading the section "REGULATING THE DETERGENT SOLUTION".
8. The machine will now begin to work with full e󰀩ciency until the battery is at or until the detergent solution has nished.
SCRUBBING WITHOUT DRYING
To carry out “SCRUBBING WITHOUT DRYING” tasks, proceed as follows:
1. Sit on the driver’s seat and turn on the machine.
2. Lower the brush head body by turning the brush head control lever (3) on the rear part of the steering column (Fig. 3).
3. Check to make sure that the detergent solution tap is completely open. If this is not the case, adjust the lever (5) on the left-hand side of the
steering column (Fig. 5).
4. Press the drive pedal (6) (Fig. 6) to begin moving the machine.
N.B.: once the drive pedal has been pressed, the brush head body will begin to descend into its working position.
N.B.: once the brush head body has reached its working position, the corresponding gear motors will begin to function and the solenoid
valve will begin to dispense the detergent solution.
5. During the rst few metres, check that the detergent solution coming out is suitable for the task in hand. If it isn't, adjust it after reading
the section "REGULATING THE DETERGENT SOLUTION".
6. The machine will now begin to work with full e󰀩ciency until the battery is at or until the detergent solution has nished.
N.B.: if the drive pedal is released during work, the gear motors (on the brush head) and the solenoid valve will stop working.
N.B.: when lling the solution tank, it is good practice to empty the recovery tank using the special drainage hose.
