ADJUSTING THE SIDE BRUSH (SWEEPING VERSION)
If the side brush does not channel the dirt e󰀩ciently towards the centre of the machine, you must adjust its height in relation to the ground,
as follows:
1. Sit on the driver’s seat.
2. Insert the key (1) into the main switch on the control panel. Bring the main switch to its "I" position by turning the key (1) a quarter turn
clockwise (Fig. 1).
N.B.: as soon as the machine turns on, the control board will perform a diagnostics procedure, during which the red LED indicator (2)
on the control panel (Fig. 2) will remain on.
N.B.: if the control board's diagnostics procedure returns a positive outcome, the red LED indicator (2) on the control panel (Fig. 2)
will turn o󰀨, and an acoustic signal will sound indicating that the work operations may be initiated.
3. Press the side brush head activation - deactivation button (17), on the left side of the steering column (Fig. 19).
N.B.: when the side brush is in function, the LED indicator light inside the button (17) will be on.
4. Lower the brush head body by turning the brush head control lever (3) on the rear part of the steering column (Fig. 3).
5. Press the drive pedal (6) to begin moving the machine (Fig. 6).
N.B.: only after the drive pedal has been pressed does the central brush head body and side brush begin to descend to the working
position.
1. As soon as the central brush head is in the working position, carry out the procedures for securing the machine (see the section
"SECURING THE MACHINE”).
2. Go to the right side of the machine.
3. Using the right equipment (not supplied with the machine) loosen the counter nut (18) (Fig. 20).
4. Using the right equipment (not supplied with the machine) loosen the adjusting screw (19) (Fig. 21), until the bristles of the brush are
squashed on the ground by about two centimetres.
5. Once the adjustment is nished, tighten the counter nut and move on to the left side brush.
DISPOSAL
Dispose of the machine in accordance with the waste disposal regulations in force in the
country in which the machine is being used.
