REPLACING THE SIDE SQUEEGEE SPLASHGUARD RUBBER BLADES
If the splashguard rubber blades of the side squeegee are damaged they cannot work properly, namely they cannot convey the dirty detergent
solution towards the squeegee, therefore the rubber blades need to be checked. To replace the brush head splash guards, proceed as follows:
1. Extract the vacuum hose (1) from the vacuum nozzle on the squeegee body (Fig. 1).
2. Completely unscrew the knobs (2) in the squeegee body's pre-assembly (Fig. 2).
3. Remove the squeegee body from the slits in the squeegee connector (Fig. 3).
4. Using the right equipment (not supplied with the machine) remove the screw (13) (Fig. 12).
5. Using the right equipment (not supplied with the machine) remove the nut (14) (Fig. 13).
6. Remove the left side squeegee (15) from the machine (Fig. 14).
7. Using the right equipment (not supplied with the machine) remove the splashguard rubber blade xing screws (16) (Fig. 15).
8. Remove the old splashguard rubber blades (17) and replace them with new ones (Fig. 16).
9. Repeat the operations in the reverse order and reassemble all the parts, then move on to the right side squeegee.
N.B.: remember to put the blade compression plate (18) between one splashguard rubber blade and the other (Fig. 16).
N.B.: when adjusting the side squeegee remember to leave about 10 mm of the threaded part beyond the self-locking anged nut (14)
(Fig. 12).
FILLING BRAKING SYSTEM OIL BASIN
If a braking system anomaly alarm is activated when you are working, quickly stop the machine and check the oil level in the machine's brake
system.
To check and top up the oil in the braking system, proceed as follows:
1. Using the right equipment (not supplied with the machine) remove the screws (19) xing the front fairing to the steering column (Fig. 17).
2. Using the handles (20), remove the fairing (21) from the machine and lay it on the ground (Fig. 18).
3. Check the level of oil in the basin (22), if necessary adding fresh oil.
4. To top up the braking system liquid basin, remove the cap-oat (23) (Fig. 19).
5. Put the brake liquid into the basin, being careful not to add too much.
N.B.: for the machine's braking system, use "Shell brake uid dot 4" brake uid.
CAUTION: to prevent serious injuries carefully read the product's safety sheet.
N.B.: the place given over to this operation must comply with current environmental protection regulations.
4. Remove the splash guards (12) from the left splash guard body and replace it with a new one or else turn it around (Fig. 11).
5. Repeat the operations in reverse order to reassemble all the parts.
6. Repeat the operations just carried out also for the right side casing as well.
