AUTOMATIC REQUEST FOR TECHNICAL ASSISTANCE (FFM VERSION)
The machine has an automatic service for activating an urgent technical assistance request. To activate this function, the operator simply needs
to press the button under the hatch bearing the symbol “SOS”.
N.B.: in order to activate this urgent technical assistance request the machine needs to be equipped with the FIMAP FLEET
MANAGEMENT kit.
N.B.: in order to send a technical assistance request the machine needs to be on and should be in a zone with data trac coverage.
VACUUM WAND KIT (OPTIONAL)
Upon request, the machine can be tted with the VACUUM WAND system that vacuums up the detergent solution more accurately. To start it do
as follows.
1. Turn the brush head control lever (3) anti-clockwise (Fig. 15); in this manner the brush head body will be raised o the oor.
2. Turn the squeegee control lever (4) clockwise (Fig. 21) to raise the squeegee body o the oor.
3. Remove all the vacuum kit components from the storage compartment.
4. Remove the vacuum tube (20) from the sleeve (21) in the squeegee body (Fig. 22).
5. Connect the wand kit vacuum tube to the squeegee vacuum tube (20) (Fig. 23).
6. Assemble the steel extension tube (Fig. 24).
7. Insert the vacuum brush into the extension tube (Fig. 25).
8. Connect the vacuum tube to the extension tube (Fig. 26).
9. Press the vacuum wand control button (22), on the back of the steering column, to activate the kit (Fig. 27).
10. Once the work is nished, remove the kit and place it back in the support that can be found on the upper part of the recovery tank cover.
N.B.: as soon as the button (22) is pressed, the LED on it comes on.
WARNING: never pick up solid matter such as dust, cigarette stubs, paper, etc.
CAUTION: never collect gases, explosive/inammable liquids or powders, nor acids and solvents! These include gasoline, paint thinners
and fuel oil (which, when mixed with the vacuum air, can form explosive vapours or mixtures), and also non-diluted acids and solvents,
acetones, aluminium and magnesium powders. These substances may also corrode the materials used to construct the machine.
CAUTION: if the machine is used in dangerous areas (e.g. petrol stations), the relative safety standards must be observed. It is forbidden
to use the machine in environments with a potentially explosive atmosphere.
SPRAY GUN KIT (OPTIONAL)
On request, the machine can be equipped with the spray gun kit. To use this, proceed as follows:
1. Turn the brush head control lever (3) anti-clockwise (Fig. 15); in this manner the brush head body will be raised o the oor.
2. Turn the squeegee control lever (4) clockwise (Fig. 21) to raise the squeegee body o the oor.
3. Release the spray gun accessory (at the back of the machine) from the retainers.
4. Activate the vacuum control kit by pressing the button (23); this is located to the rear of the steering column (Fig. 29).
N.B.: as soon as the button (23) is pressed, the LED on it comes on.
N.B.: with the spray gun kit active, the traction and work functions are deactivated.
CAUTION: when using the optional tank cleaning kit, you are advised to always wear goggles to avoid any risk of serious injury to your
eyes.
N.B.: before using the optional tank cleaning kit, check the level indicator (24) to see how much solution there is in the solution tank
(Fig. 30).
5. Activate the solution jet by pressing the lever in the tank cleaning accessory. Make sure the jet is pointing into the tank before pressing
the lever.
N.B.: to adjust the solution jet from the tank cleaning accessory, turn the knob (25) on the accessory itself (Fig. 31).
N.B.: to adjust the intensity of the solution jet from the tank cleaning accessory, turn the knob (26) on the accessory itself (Fig. 32).
N.B.: to stop the solution jet, use the lever (27) on the tank cleaning accessory (Fig. 33).
