Fimap MAGNA - Choosing and Using Brushes; Symbols Used on the Machine

CODE QTY Ø EXTERNAL
TYPE OF
BRISTLE
NOTES
447244 2 Ø460mm PPL Ø0.6 WHITE CENTRAL BRUSH
447246 2 Ø460mm PPL Ø0.9 BLACK CENTRAL BRUSH
447248 2 Ø460mm ABRASIVE CENTRAL BRUSH
447251 2 Ø440mm - CENTRAL PAD HOLDER
427709 1 Ø290mm PPL Ø0.3 BLUE SIDE BRUSH
427710 1 Ø290mm PPL Ø0.6 WHITE SIDE BRUSH
427711 1 Ø290mm PPL Ø0.9 BLACK SIDE BRUSH
427712 1 Ø290mm ABRASIVE SIDE BRUSH
427713 1 Ø280mm - SIDE PAD HOLDER
CODE QTY Ø EXTERNAL LENGTH TYPE OF BRISTLE NOTES
447963 2 200mm 856mm PPL 0.6mm CENTRAL BRUSH
447964 2 200mm 856mm PPL 0.9mm CENTRAL BRUSH
447965 2 200mm 856mm ABRASIVE CENTRAL BRUSH
437874 2 450 - PPL 1mm SIDE BRUSH
CHOOSING AND USING BRUSHES
POLYPROPYLENE BRUSH (PPL)
Used on all types of oors. Good resistance to wear and tear, and hot water (no greater than 50°C.). PPL is non-hygroscopic and therefore
retains its characteristics even when working in wet conditions.
ABRASIVE BRUSH
The bristles of this type of brush are charged with highly aggressive abrasives. It is used to clean very dirty oors. To avoid oor damage,
work only with the pressure strictly necessary.
BRISTLE THICKNESS
Thicker bristles are more rigid and are therefore used on smooth oors or oors with small joints.
On uneven oors or those with deep joints, it is advisable to use softer bristles which can enter the gaps more easily.
Remember that when the bristles are worn and therefore too short, they will become rigid and are no longer able to penetrate and clean deep
down. In this case, like with over-large bristles, the brush tends to jump.
PAD HOLDER
The pad holder is recommended for cleaning shiny surfaces.
There are two types of pad holder:
1. The traditional pad holder is tted with a series of anchor points that allow the abrasive oor pad to be held and dragged while working.
2. the CENTRE LOCK type pad holder not only has anchor points, but also a snap-type central locking system in plastic that allows the abrasive
oor pad to be perfectly centred and held without any risk of it becoming detached. This type of pad holder is recommended above all for
machines with more than one brush, where the centring of the abrasive discs is di󰀩cult.
TYPE OF BRUSH (SCRUBBING VERSION)
TYPE OF BRUSH (SWEEPING VERSION)
SYMBOLS USED ON THE MACHINE
9
Filter body position symbol:
Applied to the left-hand side of the machine to indicate the position of the solution tank's lter.
P
Extra pressure activation/deactivation lever position symbol:
Applied to the central brush head's extra pressure activation/deactivation lever.
R
Reverse gear activation/deactivation lever position symbol:
Applied to the reverse gear activation/deactivation lever.
Brush head body working position symbol:
Applied to the steering column to indicate the brush head control lever direction of rotation for bringing the brushes to their working
position.
