11
TRUCK MOUNTING / LOADING INFORMATION (CONTINUED)
DESCRIPTION CG X CG Y CG Z WEIGHT
MBH6 (No Material) 82.5 in. 9 in. 18.75 in. 7,169 lbs.
MBH6 (Full, 6 yard)* 74 in. 3 in. 26 in. 12,275 lbs.
Maximum Capacity Rating - - - 5,106 lbs.
* Assumes six (6) yards of mulch weighing 851 lbs. / cu. yd.
NOTE: All dimensions are in inches; drawings are not to scale.
MUD FLAPS
