Finn MBH6 - Page 18

12
TRUCK MOUNTING / LOADING INFORMATION (CONTINUED)
HOPPER
BASE
2.50 in. (63.5 mm)
3.37 in. (85.6 mm)
0.37 in. (9.4 mm) GAP
ITEMS PRE-INSTALLED
AT FACTORY
MATCH THROUGH HOLES:
DRILL 11/16 in. (17.5 mm) THROUGH
BOLT (3X, BOTH SIDES)
ZINC PLATED HARDWARE
M16 x 2 CLASS 10.9 - or -
5/8 - 11 (UNC) GRD 8
(OR EQUAL)
TORQUE TO 212 ft./lb. (287 N-m)
---------------
---------------
DO NOT WELD TO CHASSIS
---------------
TOP OF
FRAME RAIL
2.50 in. (63.5 mm)
< FRONT
SPRING MOUNT
