Finn MBH6 - Page 19

13
TRUCK MOUNTING / LOADING INFORMATION (CONTINUED)
2.50 in. (63.5 mm)
1.75 in. (44.45 mm)
ITEMS PRE-INSTALLED
AT FACTORY
HOPPER BODY
TRUCK CHASSIS
FRAME RAILS
---------------
ZINC PLATED HARDWARE
M16 x 2 CLASS 10.9 - or -
5/8 - 11 (UNC) GRD 8
(OR EQUAL)
---------------
TORQUE TO 212 ft./lb. (287 N-m)
DO NOT WELD TO CHASSIS
---------------
TOP OF
FRAME RAIL
3.75 in. (95.3 mm)
MATCH THROUGH HOLES:
DRILL 11/16 in. (17.5 mm) THROUGH
BOLT (4X, BOTH SIDES)
REAR >
FIXED MOUNT
