FIOCCHETTI 130 - How to Customise the Display

MNL004_EN rev. F
Pag. 20 di 56
4.2.2 HOW TO CUSTOMISE THE DISPLAY
Pressing the button , the LCD display can be customized in four different modes.
Figure 19 – display customization
Mode 1
Mode 2
Mode 3
Humidity mode
Working status and
temperature
Setpoint and temperature
Date and hour
(nnot present with DMLP
Digital Montor)
Relative humidity %
(only if humidity probe is
installed)
When Mode 1 is selected, the following strings can be visualized:
Table 2
STRING
OPERATION IN PROGRESS
PAUSE
The compressor is OFF, waiting for next cooling cycle
COOL
The compressor is ON to reach setpoint
WAITING DEFROST
After request of manual defrosting, the controller waits for the necessary conditions to
proceed automatically with defrosting
ACCESS DENIED
Attempt to access a disabled menu or after a manual defrost request if the conditions are not
suitable for such action
DEFROST
The refrigerator defrosts, warming up the evaporator
DRIPPING
Last phase of defrosting to allow evaporator dripping
RECOVERY
The compressor is ON after defrosting to re-acquire the temperature
DOOR
Door open (close immediately)
HEATING
Heating action active
PAUSE +4,5°C
S + 4.0°C +4,5°C
12:44 01/11/2017
56% Rh
+4,5°C
