MNL004_EN rev. F
Pag. 43 di 56
MODEL 700-1500
PHASE 1
In models with higher motors (700-1500 L), the condenser can be accessed directly from the outside using a ladder.
PHASE 2
Use a vacuum cleaner, air jet, or a long bristle brush to remove any dust on the condenser fins.
PHASE 3
Restore the electrical current and switch back on the device.
5.4 CONDENSATE WATER DRAINING
Defrosting causes the formation of condensate water. The water evaporates
automatically in models with motor compartment in lower position.
In some other models, water is collected in a tray, included in supply, which is set
under the unit and inserted in the corresponding slides.
This tray must be emptied frequently
Optionally, models with upper motor compartment can have a collecting tray
included for automatic condensation water evaporation.
List of Models with upper motor:
EMOTECA TWIN 700 – 1500
SUPERARTIC 700 – 700 2T
PLASMA SUPERARTIC 700 – 700 2T
LABOR 700 2T
PLASMA LABOR 700 2T
SPARK-PROOF 400 – 700
