Fig. 2.3.4-3: Overview Page 3 Symbols/EnglishOverview Page 3:
09. Generator apparent power [kVA]
10. Power Factor
Note:In the case of 3-phase generators, the voltage, the
current and the electrical power are shown on separate
pages. Each page shows the value of one of the three
phases one below the other.
Fig. 2.3.4-4: Voltage display 3-P Symbols/English/Example of the voltage display of a 3-phase generator.
Fig. 2.3.4-5: Overview Page 3 Symbols/EnglishOverview Page 3:
09. Phase/Phase voltage
10. Generator apparent power [kVA]
11. Power Factor
