Panda 5000i PMS generator
14.7.16 Kapitel/Chapter 6: Panda 5000i PMS generator - Seite/Page 45
Fig. 6.2.8-2: TThermo-switch at exhaust connectionThermo-switch at exhaust connection
If the impeller pump drops out and deliveres no more
seawater, the exhaust connection becomes extremely hot.
Fig. 6.2.8-3: Thermo-switch coilThermo-switch coil
One thermo sensor is located in the stator winding
Fig. 6.2.8-4: Oil pressure switchOil pressure switch
In order to be able to monitore the lubricating oil system, an
oil pressure switch is built into the system.
