10.5 Cable cross section
Fig. 10.5.0-1: Cable cross section
10.6 Engine oil
10.6.1 Engine oil classification
10.6.1.1 Operating range:
The operating range of an engine oil is determined by SAE class. „SAE“ is for the union of American auto engineers
(Society of Automotives Engineers).
The SAE class of an engine oil only informs over the viscosity of the oil (larger number = more viscous, smaller
number = more highly liquidly) e.g. to 0W, 10W, 15W, 20, 30, 40. The first number shows the liquid of the oil with
cold weather, the second number refers to the fluidity with heat. Complete yearly oils have usually SAE classes of
SAE 10W-40, SAE 15W-40 etc.
10.6.1.2 Quality of oil:
The quality of an engine oil is specified by the API standard („American Petroleum Institutes“).
The API designation is to be found on each engine oil bundle. The first letter is always a C.
Panda PMS 50 MB 40 30 60 8 8
Panda PMS 60 MB 40 40 60 8 8
Panda PMS 75 MB 40 30 60 8 8
Panda PMS-HD 7,5-4 KU 25 20 40 8 8
Panda PMS-HD 09-4 KU 25 20 50 8 8
Panda PMS-HD 12-4 KU 25 20 50 8 8
Panda PMS-HD 17-4 KU 25 25 60 8 8
Panda PMS-HD 22-4 KU 30 30 60 8 8
Panda PMS-HD 30-4 KU 30 30 60 8 8
Panda PMS-HD 40-4 KU 30 30 60 8 8
Panda PMS-HD 60-4 DZ --- --
Panda PMS-HD 70-4 DZ --- --
Panda PMS-HD 85-4 DZ --- --
Panda PMS-HD 110-4 DZ --- --
Panda PMS-HD 130-4 DZ --- --
length 1 - 3 m 4 - 6 m 7 - 10 m 11 - 15 m 16 - 20 m
16 mm² 70 A 63 A 55 A 48 A 42 A
25mm² 112 A 100 A 88 A 75 A 63 A
35mm² 145 A 130 110 100 A 90 A
50mm² 225 A 200 A 175 A 150 A 125 A
70mm² 275 A 250 A 225 A 195 A 170 A
95mm² 340 A 300 A 280 A 260 A 220 A
Generator type Ø Cooling water conduit Ø Exhaust conduit
[mm]
Ø Fuel conduit
Freshwater
[mm]
Seawater
[mm]
Supply
[mm]
Return
[mm]
