Fischer Panda Panda 5000i PMS - Diameter of Conduits

Tables
Seite/Page 98 - Kaptitel/Chapter 10: Tables 14.7.16
³ 0,35 l/kW electrical power, the randomized values between 30 % and 80 %
of the rated speed
10.4 Diameter of conduits
Fig. 10.4-1: Diameter of conduits
Rated speed 1500 rpm 2700 rpm
Idle running speed 1800 rpm 1600 rpm
Valve clearance (engine cold) 0,2 mm 0,18 - 0,22 mm
Cylinder head nut torque 68 Nm 93,1 - 98 Nm
Compression ratio 22:1
Lubrication oil capacity 6,0 l 9,5 l
Fuel consumption ³ approx. 1,20-
3,36 l
approx. 1,95 -
5,2 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
28-40 l/min 55-80 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 70 Ah
equivalent
12 V 136 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 70 mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
Panda 25i Panda 45i
Generator type Ø Cooling water conduit Ø Exhaust conduit
[mm]
Ø Fuel conduit
Freshwater
[mm]
Seawater
[mm]
Supply
[mm]
Return
[mm]
Panda PMS 3,8 ND 12 12 30 8 8
Panda PMS 4,5 ND 12 12 30 8 8
Panda PMS 4500 SCB 12 12 30 8 8
Panda PMS 5000 SCE 12 12 30 8 8
Panda PMS 4500 FCB 12 12 30 8 8
Panda PMS 5000 LPE 16 16 30 8 8
Panda PMS 6000 ND 20 20 40 8 8
Panda PMS 8000 NE (8 mini
Digital)
20 20 40 8 8
Panda PMS 9000 ND 20 20 40 8 8
Panda PMS 12000 NE (12 mini
Digital)
20 20 40 8 8
15 mini Digital 20 20 40 8 8
Panda PMS 14000 NE 20 20 40 8 8
Panda PMS 18 NE (16 Digital) 25 20 50 8 8
Panda PMS 24 NE (22/25 Digital) 25 20 50 8 8
Panda PMS 30 NE 25 20 50 8 8
Panda PMS 33 KU 30 25 50 8 8
Panda PMS 42 KU 30 30 50 8 8
Panda PMS 32 YA 30 30 50 8 8
Panda PMS 50 YA 30 30 60 8 8
Panda PMS 60 YA --60 88
