Fisher FIELDVUE DLC3010 User Manual

Instruction Manual
D102748X012
Field Communicator Menu Tree
October 2014
101
Figure B‐1. Hot Key
Hot Key
1 Write Lock
2 Write Lock Setup
3 Change PV
4 Enter Contstant Density
Figure B‐2. Overview
Overview
1 Device Status
2 Comm Status
3 PV is
4 Primary Variable
5 AO
6 Process Temperature
7 Device Information
Device Information
1 Identification
2 Revisions
3 Alarm Type and Security
Identification
1 HART Tag
2 Distributor
3 Model
4 Device ID
5 Instrument Serial Number
6 Sensor Serial Number
7 Final Assembly Number
8 Date
9 Descriptor
9 Message
Primary Variable
1 PV Value
2 % Range
1‐4
1‐7-1
1-7
Revisions
1 HART Universal Revision
2 Field Device Revision
3 Firmware Revision
4 Hardware Revision
5 DD Information
Process Temperature
1 Proc Temp Source
2 Proc Temp
1‐6
1‐7-2
Alarm Type and Security
1 Alarm Type
2 Security
1‐7-3
Alarm Types
1 Alarm Jumper
2 Display Alert/Saturation Level
Security
1 Write Lock
2 Write Lock Setup
1‐7-3-1
1‐7-3-2
Device Status
1 Refresh Alerts
2 No Active Alerts
1‐1
1
Figure B‐3. Configure > Guided Setup
Configure
1 Guided Setup
2 Manual Setup
3 Alert Setup
4 Communications
5 Calibration
Guided Setup
1 Instrument Setup
2‐1
2
