Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
107
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Reserved AI
RESERVED_AI
81 RW ALL 0 SETUP
Data Type: Uint16
Reserved
Upgrade Progress
UPGRADE_PROGRESS
82 RO N/A 1 N/A
Data Type: Enum (Uint8)
Not used by the DVC6200f
SPEC_SHEET_VALVE
83
Valve Size
VALVE_SIZE
83.1 RW ALL NULL ALL Data Type: Visible String
Valve Class
VALVE_CLASS
83.2 RW ALL NULL ALL Data Type: Visible String
Rated Travel
RATEDTRAVEL
83.3 RW ALL 0.00 ALL Data Type: Float
Actual Travel
ACTUAL_TRAVEL
83.4 RW ALL 0.00 ALL Data Type: Float
Shaft Stem Diameter
SHAFT_STEM_DIA
83.5 RW ALL 0.00 ALL Data Type: Float
Packing Type
PACKING_TYPE
83.6 RW ALL NULL ALL Data Type: Visible String
Inlet Pressure
INLET_PRESSURE
83.7 RW ALL 0.00 ALL Data Type: Float
Outlet Pressure
OUTLET_PRESSURE
83.8 RW ALL 0.00 ALL Data Type: Float
SPEC_SHEET_TRIM
84
Seat Type
SEAT_TYPE
84.1 RW ALL NULL ALL Data Type: Visible String
Leak Class
LEAK_CLASS
84.2 RW ALL
ANSI Seat Leakage
Classification
1: I
2: II
3: III
4: IV
5: V
6: VI
7: BFW
8: STD AIR
9: BFW II
10: BFW III
11: BFW IV
12: BFW V
13: BFW VI
14: 1/10th of IV
15: Bubble Tight
1= I ALL Data Type: Enum (Uint8)
Port Diameter
PORT_DIAMETER
84.3 RW ALL 0.00 ALL Data Type: Float
Port Type
PORT_TYPE
84.4 RW ALL
1=balanced
2=unbalanced
0 ALL Data Type: Enum (Uint8)
Flow Direction
FLOWDIRECTION
84.5 RW ALL
1=up
2=down
0 ALL Data Type: Enum (Uint8)
Push Down To
PUSH_DOWN_TO
84.6 RW ALL
1=open
2=close
0 ALL Data Type: Enum (Uint8)
Flow Tends To
FLOW_TENDS_TO
84.7 RW ALL
1=open
2=close
0 ALL Data Type: Enum (Uint8)
Unbalanced Area
UNBALANCED_AREA
84.8 RW ALL 0.00 ALL Data Type: Float
Trim Style 1
TRIM_STYLE_1
84.9 RW ALL NULL ALL Data Type: Visible String
Trim Style 2
TRIM_STYLE_2
84.10 RW ALL NULL ALL Data Type: Visible String
-Continued-
