Instruction Manual
D103412X012
Parts
July 2013
250
Kit Description Part Number
9* Remote Mount Feedback Unit Kit (see figure 8‐5)
[remote housing assembly (key25); hex socket set
screw (key 58); 1/2 NPT pipe plug (key 62); wire retainer, qty 2
(key 131); terminal cover (key 255); o-ring (key 256); gasket
(Housing A only, used for GX actuator) (key 287); seal
(Housing A only, used for GX actuator) (key 288)
Housing A (used for GX actuator) GE46670X012
Housing B (used for all actuators except GX) GE40178X012
10* Feedback Array Kit
Sliding Stem (Linear)
[kit contains feedback array and hex socket cap screws, qty. 2,
with hex key and alignment template. 210 mm (8-1/4 inch) kit
also contains insert]. Stainless steel kits only for use with
stainless steel mounting kits.
7 mm (1/4-inch)
Aluminum GG20240X012
19 mm (3/4-inch)
Aluminum GG20240X022
Stainless steel GG13199X012
25 mm (1-inch)
Aluminum GG20240X032
Stainless steel GG13199X022
38 mm (1-1/2 inch)
Aluminum GG20240X042
Stainless steel GG13199X032
50 mm (2-inch)
Aluminum GG20240X052
Stainless steel GG13199X042
100 mm (4-inch)
Aluminum GG20240X062
Stainless steel GG13199X052
210 mm (8-1/4 inch)
Aluminum GG20243X012
Stainless steel GG13199X072
Rotary
[kit contains feedback assembly, pointer, and travel indicator
scale]. Stainless steel kits only for use with stainless steel
mounting kits.
Aluminum GG10562X012
Stainles steel GG10562X022
Parts List
Note
Part numbers are shown for recommended spares only. For part
numbers not shown, contact your Emerson Process Management sales
office.
Parts with footnote numbers are available in parts kits; see footnote
information at the bottom of the page.
Key Description
Housing (see figure 8‐2 and 8‐4)
DVC6200f and DVC6205f
1 Housing
(7)
11 Drive Screw (2 req'd) (DVC6205f only)
20 Shield (DVC6205f only)
52 Vent, plastic
(2)
74 Mounting Bracket (DVC6205f only)
248 Screw, hex head (4 req’d) (DVC6205f only)
249 Screw, hex head (4 req’d) (DVC6205f only)
250 Spacer (4 req’d) (DVC6205f only)
267 Standoff (2 req’d) (DVC6205f only)
271 Screen
(7)
287 Gasket, Housing A only (used for GX actuator) (DVC6200f only)
288 Seal, Housing A only (used for GX actuator) (DVC6200f only)
Common Parts
(see figure 8‐2, 8‐3, and 8‐4)
DVC6200f and DVC6205f
16* O‐ring
(1)
(3 req'd)
29 Warning label, for use only with LCIE hazardous area
classifications
33 Mach Screw, pan hd, SST
(2)
(3 req'd)
38 Cap Screw, hex socket, SST
(2)(6)
(3 req'd)
43* Cover Assembly (includes cover screws)
Standard 38B9580X022
Extreme temperature option
(fluorosilicone elastomers) 38B9580X032
48 Nameplate
49 Screw, self tapping (2 req'd)
(6)
61 Pipe Plug, hex socket
(6)
Housing A with relay C (2 req'd ) (used for GX actuator)
Housing A with relay B (1 req'd) (used for GX actuator)
Housing B with relay B and C (1 req'd)
(used for all actuators except GX)
Not required for relay A
63 Lithium grease (not furnished with the instrument)
64 Zinc based anti‐seize compound (not furnished with the
instrument)
65 Lubricant, silicone sealant (not furnished with the instrument)
154 Retaining Ring
(2)
(3 req'd)
236 Screen (required for relay B and C only)
(7)
237 Module Base Seal
(1)
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
6. Available in the Spare Module Base Assembly Kit
7. Available in the Spare Housing Assembly Kit
