Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Parts
July 2013
252
Key Description
Feedback Connections Terminal
Box (see figure 8‐4)
DVC6205f
4 Terminal Box Cap
34* O‐ring
(1)(4)
36* O‐ring
(1)(4)
58 Set Screw, hex socket, SST
(2)
62 Pipe Plug, hex hd, SST
64 Anti‐seize compound (not furnished with the instrument)
262 Adapter
263* O-ring
Standard 1F463606992
Extreme temperature option, (fluorosilicone) 1F4636X0092
264 Terminal Box Assembly, remote
PWB Assembly
(see figure 8‐2 and 8‐4)
DVC6200f and DVC6205f
Note
Contact your Emerson Process Management sales office for PWB
Assembly FS numbers.
50* PWB Assembly
Standard Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance DIagnostic
Fieldbus Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Fieldbus Logic
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Key Description Part Number
Pressure Gauges, Pipe Plugs, or
Tire Valve Assemblies
(see figure 8‐3)
DVC6200f and DVC6205f
47* Pressure Gauge, nickel‐plated brass case, brass connection
Double‐acting (3 req'd); Single‐acting (2 req'd)
PSI/MPA Gauge Scale
To 60 PSI, 0.4 MPa 18B7713X042
To 160 PSI, 1.1 MPa 18B7713X022
PSI/bar Gauge Scale
To 60 PSI, 4 bar 18B7713X032
To 160 PSI, 11 bar 18B7713X012
PSI/KG/CM
2
Gauge Scale
To 60 PSI, 4 KG/CM
2
18B7713X072
To 160 PSI, 11 KG/CM
2
18B7713X082
66 Pipe Plug, hex hd
For double‐acting and single‐acting direct w/gauges
(none req'd)
For single‐acting reverse w/gauges (1 req'd)
For all units w/o gauges (3 req'd)
67 Tire Valve, used with Tire Valve Option only
Double‐acting (3 req'd); Single‐acting (2 req'd)
*Recommended spare parts
