Technical Description HyPower-Geko
20 FläktGroup DC-2014-0022-GB 2018-05/R5 • Subject to modifications
2.6.2 Technical data and capacity of condensate pump
The max. delivery head of the pump is 8 m, the maximum volume flow is 14 l/h. In the
fig. 2-14 the power of the pump is specified in l/h relative to the delivery head.
Technical data of condensate pump
Condensate pump capacity
Pos. 1: Condensate pump
Pos. 2: Suction hose with suction basket
Pos. 3: Pressure hose for on-site condensate
connection (1.5 m long)
Pos. 4: Fill level sensor with protective cover
Fig. 2-13: Condensate pump
Technical data Values
Operating voltage 230 V AC/50 Hz
Starting current max. 0.07 A
Operating current 0.02 A
Power input 4.7 W
Protection class IP64
Max. pump head 8 m
Max. water flow rate 14 l/h
Sound power level with H = 0 m 31 dB(A)
with H = 1 m 32 dB(A)
Tab. 2-18: Technical data of condensate pump
Fig. 2-14: Condensate pump capacity (pump head/volume)
