HyPower-Geko Electrical connection
FläktGroup DC-2014-0022-GB 2018-05/R5 • Subject to modifications 61
6.5 Overview of the FläktGroup MATRIX control electronics
MATRIX
2001
MATRIX control electronics are built into
the electric switch cabinet.
The following table illustrates different
controller circuit boards.
In order to enable you to make the nec-
essary connections, the following PCB
layouts illustrate the controller type
installed in each case.
You can also check the controller type
(e.g. MATRIX 3001) in the wiring dia-
gram attached to the inside of the switch
cabinet panel or on the label of the
printed circuit board.
300140014001+IO
Fig. 6-7: Overview of controller types
