5.4 Heating and cooling water connections for units with factory-mounted valves
5.4.1 Mounting connections
• At the beginning of the fitting procedure, remove caps on the water inlet and outlet
pipes.
• Fit the connections while ensuring they are free of mechanical stress.
Risk of damage to the unit!
During installation, the connecting nut on the heat exchanger must be countered
using a suitable tool. All on-site and factory-provided piping and valves with cooling
medium that are not fitted directly above the condensate pan must be insulated on-
site by others.
Valve key
Code number k
vs
value
Connection code
Cooling or heating valve
(2 and 4-pipe system)
Heating valve
(4-pipe system)
012
3
4
5
k
vs
value
m
3
/h
External
thread, flat
sealing
Solder fitting
for Cu tube
External
thread, flat
sealing
Solder fitting
for Cu tube
External
thread, flat
sealing
Solder fitting
for Cu tube
VGH.## 03.L
VGH.## 03.R
VGH.## ## ## 03.L
VGH.## ## ## 03.R
0.25 R1/2" ∅ 12 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 04.L
VGH.## 04.R
VGH.## ## ## 04.L
VGH.## ## ## 04.R
0.40 R1/2" ∅ 12 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 06.L
VGH.## 06.R
VGH.## ## ## 06.L
VGH.## ## ## 06.R
0.63 R1/2" ∅ 12 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 10.L
VGH.## 10.R
VGH.## ## ## 10.L
VGH.## ## ## 10.R
1.00 R1/2" ∅ 12 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 16.L
VGH.## 16.R
VGH.## ## ## 16.L
VGH.## ## ## 16.R
1.60 R1/2" ∅ 12 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 25.L
VGH.## 25.R
VGH.## ## ## 25.L
VGH.## ## ## 25.R
2.50 R3/4" ∅ 15 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 40.L
VGH.## 40.R
VGH.## ## ## 40.L
VGH.## ## ## 40.R
4.00 R3/4" ∅ 15 mm R3/4" ∅ 15 mm R3/4" ∅ 15 mm
VGH.## 63.L
VGH.## 63.R
VGH.## ## ## 63.L
VGH.## ## ## 63.R
6.30 R5/4" ∅ 22 mm R1" ∅ 22 mm R1" ∅ 22 mm
VGH.## 80.L
VGH.## 80.R
VGH.## ## ## 80.L
VGH.## ## ## 80.R
8.00 R5/4" ∅ 22 mm R1" ∅ 22 mm R1" ∅ 22 mm
Tab. 5-3: Overview of valve connections
User instructions!
All control valves, ball valves or shut-off valves as well as other valve accessories
are not components of the unit, but always separately enclosed in the packaging.
The assembly should be carried out on-site according to the attached instructions
of the valve accessory.
