7 Connection FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 55
7.1.1.2 Transducer Cable with Plastic Cable Jacket and Stripped Cable Ends
• Remove the left blind plug for the connection of the transducer cable (see Fig. 7.7 or Fig. 7.8).
• Open the cable gland of the transducer cable. The compression part remains in the cap nut.
FLUXUS F704
• Push the transducer cable through the cap nut and the compression part.
• Prepare the transducer cable.
• Cut the external shield and brush it back over the compression part.
• Screw the gasket ring side of the basic part into the housing of the transmitter.
• Insert the transducer cable into the housing.
• Fix the cable gland by screwing the cap nut onto the basic part.
• Connect the transducer cable to the terminals of the transmitter (see Fig. 7.1, Fig. 7.7 and Tab. 7.2).
FLUXUS F705, FLUXUS F706
• Push the transducer cable through the cap nut, the compression part, the basic part and the sealing ring (sealing ring:
only for cable gland M20, not for cable gland 1/2 NPS).
• Prepare the transducer cable.
• Cut the external shield and brush it back over the compression part.
• Insert the transducer cable into the housing.
• Fix the cable gland by screwing the cap nut onto the basic part.
• Fix the transducer cable by tightening the cable gland with the counter nut.
• Connect the transducer cable to the terminals of the transmitter (see Fig. 7.2, Fig. 7.8 and Tab. 7.2).
Attention! Observe the "Safety Instructions for the Use in Explosive Atmosphere" (see document SIFLUXUS).
Attention! For good high frequency shielding, it is important to ensure good electrical contact between the exter-
nal shield and the cap nut (and the housing).
Attention! For good high frequency shielding, it is important to ensure good electrical contact between the exter-
nal shield and the cap nut (and the housing).
Tab. 7.2: Terminal assignment
terminal connection
AV transducer (core)
AVS transducer (internal shield)
ARS transducer (inner shield)
AR transducer (core)
