15 Data transmission
15.1 FluxDiagReader/FluxDiag FLUXUS G801
2020-06-26, UMFLUXUS_G801V1-0EN
124
15 Data transmission
The data can be transmitted to the PC via the communication interface (process interface RS485 (optional) or service
interface RS232) of the transmitter.
15.1 FluxDiagReader/FluxDiag
With the help of FluxDiagReader and FluxDiag it is possible to display measurement data, snaps and parameter settings
on the PC and to export them as csv file. In order to use FluxDiagReader, the measurement has to be stopped.
In addition to this, FluxDiag allows to analyze and compare measurement data, to visualize them during the measurement
as well as to create reports. A permanent data transmission via FluxDiag is not recommended.
For the operation of FluxDiagReader and FluxDiag see the help function of these programs.
15.2 Terminal program
If FluxDiag is not available, the measurement data can be transmitted to a terminal program in ASCII format.
15.2.1 Online transmission
The measured values are transmitted during the measurement.
The data logger works independently of the online transmission but with the same transmission rate.
• Start the terminal program.
• Enter the transmission parameters into the terminal program. The transmission parameters of the terminal program and
the transmitter have to be identical.
Transmitter settings
• Select the program branch Output Options.
• Press ENTER.
• Select the channel for which the online transmission is to be activated.
• Press ENTER until the menu item Serial Output is displayed.
• Select yes to activate the online transmission.
• Press ENTER.
• Enter the storage rate.
• Start the measurement.
Tab. 15.1: Data transmission overview
program Data transmission
FluxDiagReader RS232 offline
FluxDiag (optional) RS232 online or offline
terminal program RS232 or RS485 online or offline
Notice!
It is recommended to use the interface RS485 for the online transmission of data. The service interface RS232
should only be used if the transmitter does not have an interface RS485.
Output Options\for Channel A
Output Options\...\Serial Output
Output Options\...\Serial Output\SEND ONLINE-HEAD
