9 Measurement
FLUXUS G801 9.1 Parameter input
83
UMFLUXUS_G801V1-0EN, 2020-06-26
9.1 Parameter input
The pipe and fluid parameters are entered for the selected
measuring point. The parameter ranges are limited by the
technical characteristics of the transducers and the
transmitter.
• Select the program branch Parameter.
• Press ENTER.
• Select a channel for which the parameters are to be
entered (here: Channel A).
• Press ENTER.
The display will not be indicated if the transmitter has only
one measuring channel.
9.1.1 Input of pipe parameters
Outer pipe diameter/pipe circumference
• Enter the outer pipe diameter.
• Press ENTER.
If the entered parameter is outside the range, an error message will be displayed. The limit is displayed.
Example: upper limit of 1100 mm for the connected transducers and for a pipe wall thickness of 50 mm
It is possible to enter the pipe circumference instead of the outer pipe diameter.
If the input of the pipe circumference is activated and zero is entered in Outer Diameter, the menu item Pipe Circumfer.
will be displayed. If the pipe circumference is not to be entered, press BRK to return to the main menu and start the parameter
input again.
Notice!
The parameters will not be stored before the program branch Parameter has been edited in its entirety.
Parameter
for Channel x
Outer Diameter
Wall Thickness
Pipe Material
Lining
Roughness
Medium
Medium Temperat.
Transducer Type
Additional cable
see annex A
Parameter\for Channel A
Parameter\Outer Diameter
Notice!
The inner pipe diameter (= outer pipe diameter - 2 × pipe wall thickness) will be calculated internally.
If the value is not within the inner pipe diameter range of the connected transducers, an error message will be
displayed.
It is possible to change the lower limit of the inner pipe diameter for a given transducer type (see section 16.9).
Outer Diameter
1100.0 MAXIMAL
