13 Outputs
In addition to the analog outputs, the transmitter can also be equipped with binary and frequency outputs.
13.1 Installation of a binary output
If the transmitter is equipped with binary outputs, they have to be installed and activated before they can be used:
• assignment of a measuring channel (source channel) to the binary output (if the transmitter has more than one measur-
ing channel)
• assignment of the physical quantity (source item) to be transmitted to the output by the source channel, and the proper-
ties of the signal
• activation of the installed binary output in the program branch Output Options
• Select the menu item Special Funct.\SYSTEM settings\Proc. outputs.
• Press ENTER.
Selection of a binary output
• Select the binary output to be installed.
• Press ENTER.
• Select yes to install or reconfigure the output.
• Press ENTER.
• Select no to uninstall the output and to return to the previous menu item in order to select another output.
• Press ENTER.
Assignment of a measuring channel
• Select the measuring channel to be assigned to the output as the source channel in the scroll list.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Assignment of a source item
One source item has to be assigned to each selected output.
• Select the physical quantity (source item) to be transmitted to the binary output by the source channel.
• Press ENTER.
The source items and their scroll lists are summarized in the following table.
Notice!
The settings will be stored at the end of the dialog. If the menu item is quit by pressing key BRK, the changes will not
be stored.
Special Funct.\SYSTEM settings\Proc. outputs
Special Funct.\SYSTEM settings\Proc. outputs\Install Output
Special Funct.\SYSTEM settings\Proc. outputs\Enable B1
Special Funct.\SYSTEM settings\Proc. outputs\...\Source chan. B1
Special Funct.\SYSTEM settings\Proc. outputs\...\Source item
