16 Advanced functions
16.9 Modification of the limit for the inner pipe diameter FLUXUS G809
2020-06-25, UMFLUXUS_G809V2-2EN
142
Activate or deactivate the auto-snap function.
Press ENTER.
Activate or deactivate the snap ringbuffer.
Press ENTER.
Delete snaps
Select Clear Snaps.
Press ENTER.
Read snaps
Select Snaps ->Rs232.
Press ENTER.
Activation of the snap function
In order to activate the snap function, press key until DSPSNAP/VOLTAGE is displayed in the upper line.
Press ENTER.
16.9 Modification of the limit for the inner pipe diameter
It is possible to modify the lower limit of the inner pipe diameter for a given transducer type.
Enter the HotCode 071001, see section 8.4.
Enter the lower limit of the inner pipe diameter of the displayed transducer type.
Press ENTER to select the next transducer type.
16.10 Transducer temperature
It is possible to output the transducer temperature.
Enter the HotCode 007043.
Select yes to display the transducer temperature during the measurement.
Press ENTER.
Select yes to store the transducer temperature.
Press ENTER.
Special Funct.\...\DSP-SignalSnap\AutoSnap
Special Funct.\...\DSP-SignalSnap\Snap ringbuffer
Special Funct.\SYSTEM settings\Signal snap\DSP-SignalSnap\Clear Snaps
Special Funct.\SYSTEM settings\Signal snap\DSP-SignalSnap\Snaps ->Rs232
Notice!
If a transducer is used below its recommended inner pipe diameter, a measurement might be impossible.
DNmin Q-Sensor
15 mm
Show T-transd.?
no >YES<
Store T-transd.?
no >YES<
